LCS0700L
Project Unit Paramete | ||
Rated AC input power supply | V/Hz | 380±10%/50±1Hz |
Cooling Capacity Feed flow | kW L/min | 70 700 |
Hydraulic mule | kPa | 230 |
Feed temperature | ℃ | 18 |
Refrigeration input power | kW | 31 |
Heating capacity | kW | 20 |
Overall dimensions (width * depth * height) | mm | 1500*400*2400 |
Installation | / | Vertical mount |
Maximum noise pressure level（@1.5m@40℃) | dB(A) | 78（18℃@35℃,RH50%） |
Waterproof and dustproof grade | / | CIRCCITYIP54 （electronic-controlled boxIP56） |
Refrigerant | / | R410A |
Lifespan | Years | >10 |
Surface finish | / | Electrophoretic + electrostatic spraying （RAL 7035） |
LCS0600L
Project Unit Paramete | ||
Rated AC input power supply | V/Hz | 380±10%/50±1Hz |
Cooling Capacity Feed flow | kW L/min | 60 500 |
Hydraulic mule | kPa | 210 |
Feed temperature | ℃ | 18 |
Refrigeration input power | kW | 30 |
Heating capacity | kW | 20 |
Overall dimensions (width * depth * height) | mm | 1200*400*2400 |
Installation | / | Vertical mount |
Maximum noise pressure level（@1.5m@40℃) | dB(A) | 75（18℃@35℃,RH50%） |
Waterproof and dustproof grade | / | CIRCCITYP54 （electronic-controlled boxIP56） |
Refrigerant | / | R410A |
Lifespan | Years | >10 |
Surface finish | / | Electrophoretic + electrostatic spraying （RAL 7035） |
1.Improved Battery Performance:
The liquid cooling system distributes temperature more evenly, preventing the battery from overheating and thus enhancing its overall performance and stability.
During charging and discharging, it avoids uneven temperatures that could shorten the battery's lifespan.
2.Extended Battery Life:
The operating temperature of the battery is crucial to its lifespan. The liquid cooling system can maintain the battery within the optimal temperature range, reducing thermal stress and extending the battery's service life.
3.Efficient Heat Dissipation:
Compared to traditional air cooling systems, the liquid cooling system dissipates heat more efficiently. Liquids have higher thermal conductivity, enabling them to quickly draw away heat generated by the battery.
4.Reduced Volume and Noise:
Due to its higher efficiency, the liquid cooling system typically occupies less space than air cooling systems and produces less noise during heat dissipation, making it suitable for environments sensitive to noise.
5.Better Temperature Control:
The liquid cooling system allows for more precise temperature control of the battery, avoiding localized overheating or overcooling, and thus improving the efficiency of charging and discharging.
6.Adaptability to High-Power Applications:
In high-power, high-frequency charging and discharging scenarios, the liquid cooling system can better manage extreme heat generation, ensuring the battery operates safely and stably under high loads.
