1.Applicable scenes: energy storage cabinet type
2.Cooling capacity range：3KW~10KW
3.Air supply mode:Forward and backward
Product Model | CTS0030N | CTS0060N | CTS0080N | CTS0100N | ||
Cooling capacity | kW | 3 | 6 | 8 | 10 | |
Cooling power | kW | 1.15 | 2.31 | 3.08 | 3.85 | |
EER (35°C) | 2.6 | 2.6 | 2.6 | 2.6 | ||
Cooling power | kW | 1.36 | 2.86 | 3.64 | 4.55 | |
EER (45°C) | 2.2 | 2.1 | 2.2 | 2.2 | ||
Rated water temperature | ℃ | 18 | 18 | 18 | 18 | |
Electrical heating | kW | 2 | 2 | 2 | 2 | |
Tube Diameter | DN25 | DN25 | DN25 | DN25 | ||
Flux | L/min | 40 | 50 | 60 | 90 | |
Headlift | kPa | 80 | 80 | 80 | 90 | |
Refrigerants | R410A | R410A | R410A | R410A | ||
Sizes | Broad | mm | 275 | 275 | 275 | 350 |
Deep | mm | 1100 | 1100 | 1100 | 1100 | |
High | mm | 800 | 800 | 1050 | 1100 | |
Unit weight | kg | 80 | 95 | 115 | 120 | |
Power supply | V/Hz | 220V/50Hz | 220V/50Hz | 220V/50Hz | 380V/50Hz | |
Operating temperature range | ℃ | -30～55 | -30～55 | -30～55 | -30～55 | |
Outside air circulation | Advance or retreat | Advance or retreat | Advance or retreat | Advance or retreat | ||
Installation | Embedded Horizontal | Embedded Horizontal | Embedded Horizontal | Embedded Horizontal | ||
1.Integrated design, saving site installation and commissioning costs.
2.Energy-efficient inverter compressor, inverter design, energy efficient.
3.Compressor stepless speed regulation, intelligent adjustment of cooling capacity.
4.Intelligent speed regulation of fans, matching the heat load, energy saving and noise reduction.
5.AC power supply, allowing voltage ±15% fluctuation.
6.Standard RS485 communication interface, synchronization optional CAN communication, through the RS485 (CAN) protocol to achieve BMS monitoring.
7.Incoming call self-start function, and provide a variety of alarms and protection functions.
8.High reliability, uninterrupted operation 365 days/year.
9.Small size, compact construction, protection class IPX5.
10.PTC heating to meet the heating needs of equipment in low-temperature scenarios.
11.It can run 24 hours uninterruptedly and is designed for a service life of more than 10 years;
12.Operating temperature range -30°C to 55°C.
