Full frequency conversion design, the whole machine has an annual energy efficiency ratio of up to 6.0+
Innovative high-efficiency EC fan, long-distance and efficient air supply
Ultra-large air supply and return area, sensible heat ratio of 0.92
"0" power consumption wet film humidification, no reheating
5-inch color touch screen, intelligent control
Model Number | HEX080 | HEX080 | HEX130 | HEX130 | HEX200 | HEX200 |
Function Type | Single Cooling + Heating | Constant Temperature & Humidity | Single Cooling + Heating | Constant Temperature & Humidity | Single Cooling + Heating | Constant Temperature & Humidity |
Performance Parameters | Performance Parameters | Performance Parameters | Performance Parameters | Performance Parameters | Performance Parameters | Performance Parameters |
Cooling Capacity (kW) | 7.5 | 7.5 | 12.5 | 12.5 | 20 | 20 |
Sensible Heat Ratio (W/W) | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 | 0.92 |
Reheat Capacity (kW) | 3 | 3 | 3 | 3 | - | 3 |
Humidification Capacity (kg/h) | - | 1.5 | - | 1.5 | - | 2 |
Indoor Unit Airflow (m鲁/h) | 2200 | 2200 | 3600 | 3600 | 5500 | 5500 |
Structural Parameters | Structural Parameters | Structural Parameters | Structural Parameters | Structural Parameters | Structural Parameters | Structural Parameters |
Indoor Unit Parameters | Indoor Unit Parameters | Indoor Unit Parameters | Indoor Unit Parameters | Indoor Unit Parameters | Indoor Unit Parameters | Indoor Unit Parameters |
Dimensions: Width x Depth x Height (mm) | 580x355x1650 | 580x355x1650 | 580x355x1900 | 580x505x1900 | 580x355x1900 | 580x505x1900 |
Net Weight (kg) | 76 | 79 | 83 | 86 | 122 | 125 |
Outdoor Unit Parameters | Outdoor Unit Parameters | Outdoor Unit Parameters | Outdoor Unit Parameters | Outdoor Unit Parameters | Outdoor Unit Parameters | Outdoor Unit Parameters |
Dimensions: Width x Depth x Height (mm) | 728x405x762 | 728x405x762 | 728x405x1370 | 728x405x1370 | 1020x405x1370 | 1020x405x1370 |
Net Weight (kg) | 34 | 34 | 53 | 53 | 74 | 74 |
Electrical/Connection Parameters | Electrical/Connection Parameters | Electrical/Connection Parameters | Electrical/Connection Parameters | Electrical/Connection Parameters | Electrical/Connection Parameters | Electrical/Connection Parameters |
Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz | Power Supply System 380V 3N~/50Hz |
Full Load Current (A) | 12.6 | 12.6 | 16.3 | 16.3 | 26.3 | 26.3 |
Recommended Main Cable Cross-sectional Area (mm虏) | 4x2.5+1x2.5 | 4x2.5+1x2.5 | 4x2.5+1x2.5 | 4x4.0+1x4.0 | 4x2.5+1x2.5 | 4x4.0+1x4.0 |
Recommended Distribution Switch Rating (A) | 16 | 16 | 20 | 32 | 20 | 32 |
Maximum Positive Height Difference (Outdoor Unit Above: m) | 20 | 20 | 20 | 20 | - | - |
Maximum Negative Height Difference (Outdoor Unit Below: m) | 10 | 10 | 10 | 10 | 10 | 10 |
Refrigerant R410A | Refrigerant R410A | Refrigerant R410A | Refrigerant R410A | Refrigerant R410A | Refrigerant R410A | Refrigerant R410A |
